High Speed Signal Propagation - Howard W. Johnson (twarda) [KSIĄŻKA]

Howard Johnson and Martin Graham bring together state-of-the-art techniques for building digital interconnections that can transmit faster, farther, and more efficiently than ever before. Packed with new examples and never-before-published high-speed design guidance, this book offers a complete and unified theory of signal propagation for all metallic media, from cables to pcb traces to chips. Coverage includes: - Managing tradeoffs between speed and distance - Physical theory of signal impairments: skin and proximity effects, dielectric loss, surface roughness, and non-TEM mode propagation - Generalized frequency- and step-response models - Calculation of time-domain waveforms from frequency-domain transfer functions - Differential signaling: Edge-coupled and broadside-coupled differential pairs, bends, intra-pair skew, differential trace geometry impedance, crosstalk, and radiation - Inter-cabinet connections: Coax, twisted-pair, fiber, equalizers, and LAN building wiringClock distribution: Special requirements, repeaters, multi-drop clock distribution, jitter, and power filtering - Simulation: Frequency domain simulation methods, Spice, and IBIS
